Pololu Mini Plastic Gearmotor 180:1 Offset 3mm D-Shaft Output

Product Code: PLL-00794
Availability: 3-5 business days
Planned delivery date after ordering: 2020-11-30
6.50€
Ex Tax: 5.37€

Qty

This compact, inexpensive plastic gearmotor (brushed DC motor with a 180:1 reduction gearbox) is well suited for use in small robots. While intended for operation at 4.5 V, it should run comfortably in the 3 V to 6 V range. The gearbox has a 9.7mm-long, 3 mm-diameter D-shaped output shaft that is offset from but parallel to the motor shaft, and a built-in safety clutch helps protect the gears from excessive loads.

Specifications:

  • Size: 36,5 x 20 x 27,4 mm
  • Weight: 19g
  • Shaft diameter: 3mm
  • Shaft type: offset 3mm D
  • Typical operating voltage: 4,5V
  • Gear ratio: 180:1
  • No-load speed @ 4.5V: 80 rpm
  • No-load current @ 4.5V: 80mA
  • Stall current @ 4.5V: 800mA
  • Stall torque @ 4.5V: 30 oz
