Verbatim LED maitinimo šaltinis AR111 230V-11.5VAC 0-70W

Prekės kodas: OL.ZAS-VERBATIM-12VAC
Prieinamumas: Turime parduotuvėje Vilniuje
10.62€ 11.80€
Be mokesčių: 8.78€


Verbatim AR111 LED maitinimo blokas, Vin: 230V, 50/60Hz, 0.29A Vout: 11.5VAC, 0-70W

skirtas: AR111 Verbatim 12VAC, matmenys: 113x44x28mm

Product Information
  • 12V LED-compatible electronic transformer
  • High efficiency (95%)
  • Dimmable with leading and trailing edge dimmers
  • Captured terminal screws
  • Long converter life of 50,000 hours

Primary Voltage Range (V): 220 - 240
Frequency (Hz): 50/60
Input current (A): 0.29
Secondary Voltage (V): 11.5 VAC
Lamp Wattage (W): Halogen lamp 0-70 (0-45W recommended for 12V LED lamp)
Efficiency (%): >95
Power Factor: >0.99
Ambient Temperature ta (°C): 50
Max Case Temperature tc (°C): 80
Input Capacitance (nF): 100
Dimming: Leading and trailing edge dimmers
Dimensions L x W x H (mm): 113x44x28
Weight (g): 80
Safety class: II
Primary Terminal: 2-pole, screw terminal Dia. 3.5mm
Secondary Terminal: 2-pole, screw terminal Dia. 3.2mm

EN 61347-1
EN 61347-2-2
EN 55015
EN 61000-3-2
EN 61000-3-3
EN 61547

* Specifications are subject to operating with halogen lamps.
