Power supply module - 3.3V - adapter with DC -mini USB sockets Power Module with DC and Mini USB Socket

This power module is equipped with a DC 2.1/5.5mm and mini USB socket, offering versatile power options for your electronic projects.

• DC socket: Allows the connection of a power supply with a voltage from 5V to 12V DC. On the solder fields labeled 3V3 and +5V, 3.3V and power supply voltage will appear respectively. Attention: The solder field marked +5V will show the voltage of the power supply. If the power supply provides 5V, then 5V will appear on this pin.
• Mini USB socket: When powering the module via mini USB, we get 3.3V and 5V at the output of the module. The AMS1117-3.3V linear stabilizer is responsible for providing a stable 3.3V voltage. In addition, the module's outputs include GND and D+, D- signals from the mini USB socket.
• Spacing of Outlets: The module's pinouts are in a standard 2.54-mm raster for easy integration with other electronic components.

• Supply voltage (DC): 5-12V DC
• Supply voltage (mini USB): 5V DC
• Module dimensions: 24x24 mm
• The set includes: Pin strip 2.54 mm

• GND: Mass
• ID: OTG pin ID from mini USB socket
• D+, D-: Data pins from mini USB socket
• +5V: The pin on which 5V appears (when powered by mini USB) or power supply voltage (when powered from a DC outlet)
• 3V3: Voltage 3.3V DC

Please pay special attention to the problem with the output labeled +5V. When powering the module through the DC socket, the voltage on this pin will be equal to the voltage of the power supply.

If the power supply provides more than 5V, the voltage will also be higher than 5V, which may not be suitable for some components. When powered by mini USB, the +5V will always be 5V.

The power module with DC and mini USB socket is a versatile solution that provides stable 3.3V and 5V, depending on the power source. Its compact size and standard pinouts make it an ideal component for a variety of electronic projects.
