Smart plug designed for outdoor use Shelly Outdoor Plug S Gen3

Brand: Shelly Group
Product Code: 3800238070557
Availability: 4-6 business days
Planuojama gavimo data po užsakymo: 2025-05-26
34.50€
Ex Tax: 28.51€

Qty

Device identification
  • Device name: Shelly Outdoor Plug S Gen3

  • Device model: S3PL-20112EU

  • Device SSID: ShellyOutdoorSG3-XXXXXXXXXXXX

  • BLE ID: 0x1853

Short description

The Shelly Outdoor Plug S Gen3 is one of the first Shelly devices designed for outdoor use to support Matter.

Shelly Outdoor Plug S Gen3 (Device) is a smart plug/socket with power measurement and overheat protection, allowing you to remotely control electrical appliances via your mobile phone, tablet, PC or home automation system. It can operate independently on a local Wi-Fi network or can be controlled via cloud home automation services.

The Shelly Outdoor Plug S Gen3 can be accessed, set up, and monitored remotely from any location where the user has an internet connection, as long as the device is connected to a Wi-Fi router and the internet.

The device has a built-in web interface that allows you to monitor and control the device and adjust its settings.

Main functions
  • IP44 protection

  • Matter support

  • Next-generation Wi-Fi smart plug with multi-color LED indication

  • Scripting (only supported when Matter is not enabled)

  • Wi-Fi range extender

  • BLE gateway

  • Electricity metering (in the Shelly Smart Control app)

  • Schedules

  • High compatibility with third-party home automation systems

  • Local actions

  • Shellly Cloud / Shellly Smart Control app support (optional)

  • Virtual components

Use cases
  • Garden automation:
    Automate garden lighting strips, electric grills, electric stoves or other garden appliances to control their operation and consumption and make sure that energy is not wasted.

  • Easy to use and integrate with other Matter devices

  • Compatible with Apple devices (via Matter)

  • Use as a colored night light:
    Night mode with custom settings
    Night mode reduces the brightness of the Shelly Outdoor Plug Gen3's LED indicator at night so you can sleep undisturbed.

  • No forgotten devices:
    Monitor and easily control all your plugged-in devices with just a few taps on your phone. With a built-in countdown timer and locally saved schedules, the Shelly Outdoor Plug Gen3 can automatically turn off any forgotten devices after an hour, saving energy.
    Example: "The Shelley Shelley heater can be connected to the mains, e.g.: For example, an iron, smaller ovens, electric heating radiators

  • Reduce energy waste by automating electrical appliances:
    Automate devices in your office that are not used at night or on weekends by simply adding the Shelly Plug S Gen3. Now you can set smart schedules that will turn off the power to all unused electrical devices on weekdays from 7:00 PM to 7:00 AM and from 7:00 PM on Friday to 7:00 AM on Monday. This will cut the energy consumption of these devices by half, which will significantly optimize your monthly energy costs.
    Example: Use schedules to automate smaller ovens, electric radiators, and infrared heaters

  • A water purifier that follows weather conditions:
    If you live in a big city, the air can be quite polluted, especially during the fall and winter seasons. Thanks to the Shelly OutDoor Plug Gen3's scripting features, you can pull data directly from your air pollution monitor and set your old air purifier in your home to turn on when the air pollution outside increases.
    Example: Using scripts, you can automate an air purifier device and turn it on/off based on third-party data.

  • Easily dimmable night light for children's comfort:
    Now you can set the color and glow level of the Shelly Outdoor Plug Gen3's LED indicator and use it as a subtle light in the kids' room at night.

Main areas of use
  • Living quarters

  • MDU (Multi-family buildings - apartments, condominiums, hotels, etc.)…

  • Light commercial activities (small office buildings, small retail/restaurant/gas station buildings, etc.)…

  • Government and municipal institutions

  • University/college

  • Farming

  • Garden/yard

Connections Amazon Alexa supported capabilities

Yes

Google Smart Home supported features

Yes

Samsung SmartThings supported features

Yes

Simplified internal diagram

Simplified hardware architecture

Device electrical interfaces Input
  • 1 CEE 7/7 plug

Exit
  • 1 CEE 7/3 (Type F / Schuko) socket

Connectivity
  • Wi-Fi

  • Bluetooth

Security function
  • Overheating protection

  • Surge protection

  • Surge protection

  • Surge protection

Supported load types
  • Resistive (incandescent bulbs, heating devices)

  • Capacitors (capacitor batteries, electronic equipment, motor start capacitors)

  • Inductive (LED drivers, transformers, fans, refrigerators, air conditioners)

User interface Inputs
  • One button

    • Press to turn the output on/off.

    • Press and hold for 3 seconds to check the status (only available when the output is off).

    • Press and hold for 5 seconds to reboot (Available up to 60 seconds after device is powered on).

    • Press and hold for 10 seconds to reset to factory settings (available up to 60 seconds after connecting to the device).

Outputs
  • LED indication

    • When connecting to the mains for the first time:

      • The blue light flashes to indicate access point mode.

    • After successfully connecting to the Wi-Fi network and turning the power on/off again:

      • The red light blinks slowly, indicating that the device is reconnecting to the Wi-Fi network.

      • A steady red light indicates that the Device cannot reconnect to the Wi-Fi network.

  • When the output is on:

    • Energy consumption is represented by a uniform color change (default value):

      • Green light when 0% power limit is set

      • Yellow light when 50% power limit is set

      • Red light when 100% power limit is set

      The user can select the brightness (default brightness is 100%).

    • Color can be selected (Default color - green, default brightness - 100%)

    • Off

  • When the output is off:

    • Off (default setting):

    • Selected color (default color - red, default brightness - 100%)

  • When an OTA update is in progress:

    • Red light is flashing

Specifications

Quantity

Value

Physical

Size (HxWxD):

56x56x103 ±0.5mm / 2.21x2.21x4.55 ±0.02in

Weight:

85 ±1g / 3 ±0.04oz

Compatible sockets:

CEE 7/1, CEE 7/3 (Type F / Schuko) or CEE 7/5 (Type E)

Compatible plugs:

CEE 7/2, CEE 7/4 (Type F / Schuko), CEE 7/7, CEE 7/16 (Type C) or CEE 7/17

Housing material:

Plastic with protective silicone roofing felt cover for the socket

Color:

Mocha

Environmentally friendly

Ambient temperature:

25°C to 51°C / -13°F to 125°F

Humidity

15-85% RH

Max height

2000 m / 6562 ft

Kerosene wire temperature:

750°C

Ingress protection:

IP44

Forced cooling required:

No

Power plant

Electricity supply:

230V~ 50/60Hz

Electricity consumption:

< 1W

Rated impulse withstand voltage:

2500V

Nominal parameters of output circuits

Maximum switching voltage:

230 V~

Maximum switching current:

12 A

Maximum output power:

2500 W (resistive load only)

Number of start-up cycles:

10000

Overvoltage category:

II

Job type:

S1

Switching type:

One-way

Switch configuration:

SPNO (single pole, normally open)

Circuit Breaker Type:

Microcurrent

Sensors, meters

Internal temperature sensor:

Yes

Voltmeter (alternating current):

Yes

Meter (alternating current):

Yes

Electricity and energy meters:

Yes

Radio

Wi-Fi

Protocol:

802.11 b/g/n

RF band:

2401-2473 MHz

Max RF power:

<10 dBm

Wi-Fi connection range:

From 50 m / 164 ft outdoors, to 30 m / 98 ft indoors (depending on local conditions)

Bluetooth

Protocol:

4.2

RF band:

2400 - 2483.5 MHz

Max RF power:

< 4 dBm

Rank:

From 30 m / 98 ft outdoors, to 10 m / 33 ft indoors (depending on local conditions)

Microcontroller unit

CPU:

ESP-Shelly-C38F

Flash:

8MB

Firmware options

Webhooks (URL actions):

20 with 5 URLs in each hook

Scripting:

Yes

MQTT:

Yes

CoAP:

No
