SONOFF TH Elite Smart Temperature and Humidity Monitoring Switch - 16A

Brand: Sonoff
Product Code: THR316D
Availability: Vilnius Store In Stock
Kaunas Store In Stock
Central Warehouse In Stock
17.00€
Ex Tax: 14.05€

Qty

SONOFF TH Elite is a Smart Temperature and Humidity monitoring switch based on ESP32. With an LCD screen, TH Elite keeps monitoring the temperature and humidity in real-time, once they reach your preset threshold or the device's on/off state changes, you will receive a push notification on the phone. Support to connect 20 A Max. high-load equipment like electric floor heating. You can replace your dry contact outputted traditional thermostat with TH Elite, to control the combi boiler or any other systems controlled by the ordinary switch. TH Elite support to review 6-Month Temp. & Humi historical data accurate to the hour. In the smart scene, temperature, humidity, on, off support settings as the trigger, on, off, and invert as execute actions. Support adding SONOFF devices to Home Assistant for control and automation through the eWeLink add-on. TH Elite turns your traditional thermostat into a smart one, automates your irrigation system, and gives you an easy way to monitor the temperature and humidity.
SONOFF TH Elite supports three kinds of temperature monitor and humidity monitor sensors - THS01 Temp. & Humi Sensor, DS18B20 waterproof Temp. sensor, and MS01 Soil Moisture Sensor. The sensor connector is upgraded to RJ9, supporting hot-plugging and making the connection more stable and reliable.
The RL560 sensor extension cable can connect the SONOFF temperature and humidity sensors to extend your device's distance. THS01, DS18B20 can be extended to 60 m, and MS01 Soil Moisture Sensor can be extended to 10 m.

Main features:

  • Support to connect 20 A Max. high load, dry contact output
  • Real-time monitoring of temperature and humidity data, the screen refreshed every 5s
  • Support to review the temp. & hum history data by hour, day and month. Past 6-month history data can be exported in .xlsx format and accurate to the hour
  • Support LAN control, automatic control is more reliable. You can set up 8 automatic control programs for you to save electricity bills and create comfortable surroundings
  • Work with Alexa, Google Assistant, you can query temperature and humidity values with your voice

Specification:

  • TH Elite: 16 A, 20 A
  • Model: THR316D/THR320D
  • THR316D Input/Output: 100 - 240 V ~ 50/60 Hz 16 A Max.
  • THR320D Input/Output: 100 - 240 V ~ 50/60 Hz 20 A Max.
  • MCU: ESP32
  • Wi-Fi: IEEE 802.11 b/g/n 2.4 GHz
  • Dry contact: 5 - 30 V, 1 A Max.
  • TH Elite Working Humidity: 5% - 95% RH, non-condensing
  • TH Elite Working Temperature: -10 °C ~ 40 °C
  • Supported Sensor: THS01, DS18B20, MS01
  • THS01 Working Temp: -40 ℃ ~ 85 °C
  • THS01 Humi Measuring Range: 0 ~ 100% RH
  • DS18B20 Working Temp: -55 ℃ ~ 125 ℃
  • MS01 Humi Measuring Range: 0 ~ 100% RH
  • MS01 Operating Temp Range: 0 ℃ ~ 60 °C
  • RL560 Conductor Resistance: Max. 10 Ω
  • RL560 Insulation Resistance: Min. 5M Ω
  • Certification: TUV/CE/UKCA/WWA/FCC/RoHS/SRRC
  • Security Mode: WPA/WPA2
  • Works with: Amazon Alexa, Google Assistant
  • Casing material: PC V0
  • Product Size: 98 x 54 x 31 mm
  • Color: White
