Stepper Motor Driver HY-DIV268N-3A 12-40V 3A

Product Code: ABC-8377
EAN: 4772164002805
Availability: Vilnius Store In Stock
Kaunas Store In Stock
14.10€
Ex Tax: 11.65€

Qty

The HY-DIV268N-3A is a PWM-type controller module for powerful stepper motors, suitable for Arduino. It can supply motors for up to 3A / 42V and operate in 1/16 micro-step mode. Its unique features are also that it can operate in cold temperatures as low as -10 ° C and has built-in closed loop current control, the motor torque ripple is very small, low-speed running is very smooth. DIP switches regulate the supply current and microsteps.

Technical specs and features:
  • Suitable for: Arduino, ARM, AVR, STM32, STM8, PIC and other similar microcontrollers
  • Operating voltage: 12-42V
  • Adjustable motor supply current: up to 3 A (pulses up to 4 A)
  • Operating temp: -10 ° C to 45 ° C
  • Extremely high motor acceleration can be achieved with the module
  • Dimensions: 35 x 86 mm
  • Weight: about 200 g
  • DIP switches regulate the supply current and microsteps
  • Closed loop current control
  • Supported microsteps: 1, 1/2, 1/4, 1/8, 1/16. For quiet operation, the manufacturer recommends 1/16 step modes
  • Suitable for 2, 4 phase and 6 wire stepper motors
  • Simple direction and step control with just 2 signal connections.
  • Controller chip: HY-DIV268N-3A
Applications and external links:
  • Precise control of robotic limbs
