Stepper motor JK57HS56-2804 200 steps/rev 2.4V / 2.8A / 1.26Nm

Product Code: AN-03650
EAN: 4779044515936
Availability: Vilnius Store In Stock
Kaunas Store In Stock
26.50€
Ex Tax: 21.90€

Qty

A stepper motor, also known as step motor or stepping motor, is a brushless DC electric motor that divides a full rotation into a number of equal steps. The motor's position can then be commanded to move and hold at one of these steps without any position sensor for feedback (an open-loop controller), as long as the motor is carefully sized to the application in respect to torque and speed

Specifikacija

  • 200 žingsniu/aps (1,8 °)
  • Vardinė įtampa: 2,4 V
  • Apvijos srovė: 2,8 A
  • Apvijos varža: 0,9 Ω
  • Induktyvumas: 2,5 mH
  • Sukimo momentas 12,8 kg*cm (1.26 Nm)
  • Bipolar (4 laidai)
  • Valo skersmuo: 6,35 mm
  • Svoris: 680 g
  • Standard: NEMA 23
  • Matmenys: 56,4 x 56,4 x 56 mm
