FNIRSI TSG3020 Function Generator

Brand: FNIRSI
Product Code: TSG3020
Availability: 4-6 business days
Planuojama gavimo data po užsakymo: 2026-10-05

224.30€
Ex Tax: 185.37€

Qty

Add to Wish List

The FNIRSI TSG3020 features high signal generation accuracy and intuitive control, making it ideal for use in laboratories, workshops and in the field. The dual-channel design, up to 60 MHz output frequency, 200 MSa/s sampling rate and 14-bit resolution allow you to generate high-quality signals with minimal distortion. The device offers a wide selection of standard and arbitrary waveforms, supports six modulation types and a frequency sweep function, and a built-in frequency counter further enhances its measurement capabilities. The device is complemented by a clear touch screen, advanced signal quality improvement technologies and a robust design for use with heavy loads.

Two independent channels

The generator has two independent output channels, which allow you to generate two different signals simultaneously and facilitate more complex measurements. The maximum output frequency is 60 MHz, and the amplitude range is optimized for various load and frequency configurations. With high impedance, the range is from 2 mVpp to 20 Vpp at frequencies up to 10 MHz and from 2 mVpp to 10 Vpp at frequencies above 10 MHz. With a 50 Ω load, the generator offers a range of 1 mVpp to 10 Vpp at frequencies up to 10 MHz and from 1 mVpp to 5 Vpp at frequencies above 10 MHz. The 200 MSa/s sampling rate and 14-bit vertical resolution ensure accurate waveform reproduction, preservation of the finest details, and very low distortion.

Standard and arbitrary waveforms

The TSG3020 generates the most commonly used waveforms such as sine, square, ramp (sawtooth), pulse, noise, and DC. It also supports custom arbitrary waveforms, created point by point, allowing for accurate reproduction of even the most complex signals. VeriPoint technology allows you to generate arbitrary waveforms with sampling rates ranging from 1 µSa/s to 200 MSa/s, while maintaining full signal detail and very low jitter of less than 200 ps. ZeroSurge technology ensures the highest quality of square, pulse and sawtooth waveforms, limiting overshoot to 1% and providing very short rise and fall times of up to 13.5 ns. The result is sharp edges and greater accuracy when testing electronic circuits.

Advanced Modulation

The generator supports six modulation types (AM, FM, PM, FSK, ASK and PSK), making it ideal for testing digital communication systems and radio equipment. The frequency sweep function operates in linear or logarithmic mode, and the sweep time can be adjusted from 1 ms to 500 s with an accuracy of ±0.1%. These capabilities allow you to conveniently analyze the filter characteristics and frequency response of the systems under test. The integrated 7-digit frequency counter supports TTL signals in the range from 100 mHz to 100 MHz, measuring frequency, period and duty cycle with an accuracy of ±51 ppm.

Convenient control for every task

The FNIRSI TSG3020 ensures very high signal quality even in complex systems. Its amplitude ranges from 1 mVpp to 10 Vpp at a 50 Ω load, phase noise does not exceed -125 dBc/Hz at a frequency of 10 MHz and a deviation of 10 kHz, and harmonic distortion is less than -40 dBc in the range of 30-60 MHz. The device is easy to operate thanks to the 4.3-inch color TFT-LCD touch screen with physical buttons for quick parameter changes. During operation, the display shows the waveform preview and the current status of the generator, making it easy to configure and monitor all settings.

Extensive configuration options

The generator is equipped with comprehensive output protection functions, including channel isolation, ground fault protection and TTL-compatible sync output, ensuring safe and stable operation even under difficult conditions. An efficient cooling system with an aluminum radiator and a quiet fan maintains optimal temperature, ensuring that the device maintains stable operation even after long-term use. Non-volatile memory allows you to save up to 24 custom arbitrary waveforms and instantly recall them without reconfiguration. The TSG3020 supports continuous operation, controlled output, modulation, and sweep functions, providing great flexibility in designing measurement systems and automated test systems.

Included:

Function generator
Charging adapter
Type-C charging cable
Data cable
Measurement lead
Alligator clips
Instructions

Specifications:

Manufacturer: FNIRSI
Maximum output: 30 MHz
Sampling rate: 200 MSa/s
Vertical resolution: 14 bit
Channels: 2
Maximum output amplitude: 20 Vpp (<10 mHz) / 10 Vpp (>10 mHz)
Sine wave frequency: 1 µHz–24 MHz
Square wave frequency: 1 µHz–24 MHz
Pulse wave frequency: 1 µHz–24 MHz
Modulation types: AM, FM, PM, FSK, ASK, PSK
Sweep modes: Linear sweep, logarithmic sweep
Integrated frequency counter: 7 Digits
Screen: 4.3 inch TFT LCD screen, 480 x 272

Tags: fnirsi, tsg3020, function, generator, measuring, equipment
